Technical Specifications
| CPU | Supports two Xeon Scalable first and second generation CPUs with LGA3647 socket. Maximum support for 205W per CPU. Maximum support for 28 cores per CPU. |
| RAM | DDR4 ECC REG 16G 2666 X 4 |
| Power supply | 2200W (1+1) redundant power supply
|
| BMC | ASPEED AST2500 |
| Network chip | 1210-AT X 2 |
| RAM | Support for 16 memory Up to 2TB Optane Persistent Memory 200 Series, DDR4-2666MHZ Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz Up to 4TB 3DS ECC RDIMM DDR4-2933MHz Up to 2TB Optane DC Persistent Memory in memory mode (Cascade Lake only). |
| Supported Memory Frequencies | 2933 or 2666 or 2400 or 2133 MT per S ECC DDR4 LRDIMM(3DS),RDIMM (3DS). |
| Characters | Server Platform 4U GPU Server AS-4124GS-TNR Product Model A Server 4124GS-TNR Product Type Rackmount Product Structure 4U Processor CPU Series AMD CPU Core 128 Core CPU Model for AMD EPYC 7002 Main Board Slot 9 x PCI-E 4.0 X 16 Memory Memory Type ECC DDR4, DDR4 3200MHz ECC Memory Memory Slot Count 32 Maximum Memory Capacity 8TB Storage Hard Disk Interface Type SATA or SAS or SSD, Maximum Support 32 Blocks |
| Motherboard Interface | 2 X 8087 interfaces support 8 X SATA3.0 2 X SATA3.0 interfaces 1 X USB3.0 header, supporting two USB3.0 1 X USB2.0 header, supporting two USB2.0 1 X HD AUDIO Header |
| PCLE | 6 x PCle 3.0 x16, 1 x PCle 3.0 x4 (in x8 slot) 1 x M.2 Interface: PCle 3.0 x4 Form Factor: 22110, 2280 Key: M-Key 1 x COM pin header (2.54mm) 0.1 in pitch 9pin) |
| Temperature | Optional security bezel |
| Open Manage Software | Open Manage Enterprise, Open Manage Power Manager plugin, Open Manage Service plugin, Open Manage Update |
| Mobility | Open Manage Mobile |
| Integrations and Connections | BMC Truesight, Microsoft System Center, OpenManage Integration with ServiceNow, Red Hat Ansible Modules , Terraform Providers , VMware vCenter and vRealize Operations Manage |
| Security | Cryptographically signed firmware, Data at Rest Encryption (SEDs with local or external key mgmt) , Secure Boot, Secure Erase, Secured Component Verification (Hardware integrity check), Silicon Root of Trust , System Lockdown (requires iDRAC9 Enterprise or Datacenter), TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Embedded NIC | 2 X 1GbE LOM on Planar |
| Network Options | 1 x OCP x8 card 3.0 Note: The system allows both LOM on planar and OCP card to be installed on the system. |
| GPU Options | Up to 2 X 300 W DW or 6 X 75 W SW |
| Ports | Front Ports, 1 X USB 2.0, 1 X USB 3.0, 1 X iDRAC Direct (Micro-AB USB) port Rear Ports , 1 X USB 2.0, 1 X USB 3.0, 1 X Serial port (optional),1 X Dedicated iDRAC (RJ45) port , 1 X VGA port, 2 X Ethernet ports Internal Ports, 1 X USB 3.0 (optional) |
| PCle | Up to six PCIe slots: Slot 1: X 16 Gen5 Full height, Full length Slot 2: X 16 Gen5 Full height, Full length Slot 3: X 16 Gen4 Full height, Half length Slot 4: X 16 Gen4 Full height, Half length Slot 5: X 16 (x8 lanes) Gen4 Full height, Half length Slot 6: X 16 Gen4 Full height, Half length
|
| Dimensions | Height — (464.0 mm) 18.26 in (with feet) (508.8 mm) 20.03 in (with caster wheels) (446.0 mm) 17.60 in (without feet) Width — (200.0 mm) 7.87 in Depth — (678.2 mm) 26.70 in) (with bezel) (660.6 mm) 26 in (without bezel) |
