Technical Specifications
| Chipset | Nordic 52 series |
| Protocol | BLE 5.0 |
| Battery | Disposable Lithium-ion Battery 4000 mAh |
| Antenna | PCB antenna on the board |
| Supported devices | iOS13+/Android6.0+(BLE 4.0 and above) |
| RF Range | Transmission distance is approximately 98 ft (30 meters) in open areas when installed at ground level, and approximately 262 ft (80 meters) in line-of-sight transmission |
| Operation Voltage | 3.6 V |
| Material | ABS + PC |
| Service Life | Approximately 6 years |
| Modulation Mode | GFSK Modulation |
| Installation Method | Installation at ground level, secured with screws or specialized adhesive |
| Waterproof Rating | IP68 |
| Supports | ibeacon/eddystone |
| SDK | Android, iOS |
| Working Temperature | -40 °F to 176 °F (-40 °C to +80 °C) |
| Dimension | 4.72 in x 4.33 in x 1.10 in (120 mm x 110 mm x 28 mm) |
| Weight | 9.13 oz (260 g) |
