Features
- High Voltage Capability
- Long Distance Measurement
- Accurate Fault Location
- Multiple Testing Methods
Technical Specifications
| Work Power | AC 100 V to 240V (50 ± 1Hz) |
| Humidity | ≤85% RH |
| Sampling Frequency | 30 M, 60 M, 120 M |
| Testing Distance | Up to 102.53 mi (165 km) |
| Test Pulse | 0.2 μs to 9.9 μs, Arbitrary Adjustable |
| Deviation | No more than ±0.82 ft (±0.25 m) |
| Low Voltage Pulse Width | 0.1 μS to 2 μS |
| Low Voltage Pulse Amplitude | 100 Vpp |
| Output Power | Path Power: 100 W, Impact Power: 0 W to 200 W |
| Impact High Voltage | 0 kV to 8 kV, 0 kV to 16 kV, 0 kV to 32 kV (optional) |
| Short Circuit Current | 0 mA to 320 mA |
| Test Range | Fault Distance Measurement, Fault Point Location |
| Measurement Accuracy (Rough) | ±32.81 ft (±10 m) or ±1% (relative) |
| Measurement Accuracy (Fine) | ±0.66 ft (±0.2 m) |
| Control | 12-inch Industrial-grade Display, Single-chip Microcontroller |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimensions (W x D x H) | 16.93 in x 14.17 in x 9.06 in (43 cm x 36 cm x 23 cm) |
| Weight | 17.64 lbs (8 kg) |
