Features
- Industrial-grade LCD display
- Accurate distance measurement
- Built-in DC power supply
- Continuous waveform sampling
- Multiple testing methods
Technical Specifications
| Impact High Voltage | 0 kV to 35 kV (optional) |
| High Voltage Divider Accuracy | Level 1.5 |
| Built-In Capacitance | 4 μF |
| Discharge Power | 0 J to 2450 J |
| Charge Current | 320 mA |
| Output Voltage Polarity | Negative polarity |
| Impact Power | 400 W |
| Overcurrent Protection | 16 A (more than 3 seconds) |
| Overtemperature Protection | 185 °F (85 °C) |
| Working Power Supply | AC 220V ±10% / 50Hz ±2Hz |
| Ambient Temperature | -4 °F to +140 °F (-20 °C to +60 °C) |
| Display | Industrial-grade 5 in LCD |
| Measurement Functions | Distance, speed, and resistance measurement |
| Sampling | Automatic continuous sampling without losing discharge waveforms |
| Testing Methods | Flashover sampling and low-impulse method |
| Distance Measurement Range | Maximum: 37.2823 mi (60 km); Minimum: 49.2 ft (15 m) |
| Pre-Locating Accuracy | Absolute: ±32.8 ft (10 m); relative: ±1% |
| Built-In DC Power | 2.6V / 10.4Ah, with optional external AC 220V / 50Hz power supply |
| Volume | 16.9 in × 13.6 in × 21.5 in (43 cm × 34.5 cm × 54.5 cm) |
| Weight | Not more than 88.2 lbs (40 kg) |
