Features
- Event Map Analysis
- Multi-Wavelength Display
- OTDR Testing Function
- Built-In VFL and OLS
Technical Specifications
| Display | 7-inch multi-touch color LCD |
| Battery Endurance | Standby >15 hours, Testing >8 hours |
| VFL Output Power | 1 mW |
| Sampling Resolution | 0.3 ft (0.1 m) |
| Loss Resolution | 0.0003 dB |
| Distance Uncertainty | ± (2.6 ft + 0.005% * testing distance + resolution) |
| Audio Port | 0.14 in (3.5 mm) audio jack |
| Buzzer | 0.55 in (1.4 cm) voltage buzzer |
| Backlight Adjustment | 10-level adjustment |
| Storage | > 10,000 testing results |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Dimensions | 9.69 in x 6.81 in x 2.76 in (24.6 cm x 17.3 cm x 7 cm) |
| Weight | 3.42 lbs (1.55 kg) |
