Technical Specifications
| Working Frequency | National standard (920 MHz to 925 MHz) American Standard (902 MHz to 928 MHz) Other multinational frequency standards (customized) |
| Label Agreement | ISO18000-6C (EPC GEN2) |
| Frequency Hopping Method | Broad spectrum frequency hopping (FHSS) or fixed frequency that can be set by software |
| Color | Black |
| Antenna Parameters | 2 dBi circular polarization antenna (built-in) |
| Output Power | 12.5 dBm to 26 dBm (software adjustable) |
| Reading Distance | 1.The maximum reading distance of the tag: 1.64 ft (0.5 m) (related to factors such as transmit power, antenna type, tag type and application environment) 2.Maximum distance to write tags: 0.66 ft (0.2 m) (depending on factors such as transmit power, antenna type, tag type and application environment) |
| Operating Mode | Active mode Passive mode Answer mode (not recommended) |
| Power Interface | DC + 5 V |
| Communication Interface | USB virtual keyboard USB virtual serial port (Need to be customized) |
| Power Adapter | USB powered |
| Power Cable | Equipped |
| RS-232 Signal Line | Equipped |
| Development Kit | Provide SDK |
| Operating Temperature | -4 °F to +131 °F (-20 ℃ to +55 ℃) |
| Storage Temperature | -40 °F to +185 °F (-40 ℃ to +85 ℃) |
| Size | (107 mm x 107 mm x 24 mm) |
| Weight | 5.29 oz or 8.82 oz (150 g or 250 g) |
