Customized Passive UHF RFID Paper Label Sticker with NXP Chip, 10-Year Data Retention – The Inventory Master

NXP CODE8 RFID label for 860 MHz to 960 MHz, ISO 18000-6C. Paper base with aluminum antenna. Reads up to 13.12 ft, writes up to 9.84 ft. 10-year data retention.

SKU: TIMUHF-249 Category:

Overview

NXP CODE8 RFID label, 860 MHz to 960 MHz, ISO 18000-6C. Read up to 13.12 ft (4 m), write up to 9.84 ft (3 m). Paper base, aluminum antenna.



Technical Specifications

Performance Specifications

Frequency860 MHz to 960MHz
StandardISO18000-6C
Chip TypeNXP CODE8
Working ModeRead or write
Read Distance0 ft to 13.12 ft
(0 m to 4 m) Depends on the chip and reader
Write Distance0 ft to 9.84 ft
(0 m to 3 m) Depends on the chip and reader
Data Retention10 (yrs.)
Anti-CollisionYes

Physical Characteristics

Base MaterialPaper
Antenna MaterialAluminum
Operating Temperature-4 °F to +167 °F (- 20 ºC to + 75 ºC)
Storage Temperature14 °F to +158 °F (- 10 ºC to + 70 ºC)
Operating Humidity≤ 80 %
SizeInlay: 0.47 in x 0.94 in, Finished size 0.59 in x 1.06 in
Inlay: (12 mm x 24 mm) Finished size: (15 mm x 27 mm)
