Technical Specifications
| Frequency Range | Working frequency 902 MHz to 928 MHz or 865 MHz to 868 MHz (can be adjusted according to different countries or regions) |
| Air Interface Protocol | Support compliance with ISO-18000-6B, ISO-18000-6C (EPC G2) |
| Frequency Modulation Method | Broad spectrum frequency modulation (FHSS) or fixed frequency, which can be set by software |
| Number Of Antennas | Built-in double-feed point ceramic antenna |
| Communication Interface | USB |
| RF IC Used | PR9200 |
| Reading Distance | Read > 3.9 in (100 mm), Write > 1.9 in (50 mm) |
| Application Software Interface | Provide dynamic link library (DLL) to support secondary development |
| Reading Distance | Built-in transceiver antenna, reading distance > 11.8 in (30 cm), writing distance > 3.9 in (10 cm) |
| Power Supply | Computer USB interface for power |
| Humidity | 5 % to 95 %, non-condensing |
| Protection Class | IEC IP52 |
| Operating Temperature | -4 °F to 140 °F (-20 ºC to 60 ºC) |
| Storage Temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Size | 5.472 in x 3.386 in x 0.866 in (139 mm x 86 mm x 22 mm) |
| Weight | 4.23 oz (120 g) |
