Technical Specifications
| Interface | Specification |
| Module Compatibility | Jetson AGX Orin |
| Display | 1x HDMI |
| Ethernet | 5x Gigabit Ethernet (10×100×1000M) (W2 2×2PSE optional) 1x10G |
| USB | 6 x USB 3.0 Type A, (Integrated USB 2.0) 1 x USB2.0 + 3.2 (TYPE C) |
| M.2 KEY M | 1 x M.2 KEY M (SSD card) |
| M.2 KEY E | 1xM.2 KEY E (WIFI card) |
| FAN | 1x FAN (12V PWM) |
| Camera | 1xMIPI (MIPI to 6xCSI Camera) |
| TF_Card | 1 x TF_Card |
| SIM_Card | 1xSIM_Card |
| Function Key | 1 x Power KEY, 1 x Reset Key, 1 x Recovery Key |
| DC | power interface |
| Input Voltage | +9 to +20V DC Input at 7A |
| Input Voltage | +12 to 36V (150W) DC Input |
| Load Capacity | Above 90W |
| Work Humidity | 10% to 90% RH, non-condensing |
| Operating Temperature | -13°F to 158°F (-25°C to 70°C) |
| Storage Temperature | -13°F to 149°F (-25°C to 65°C ) |
| Dimension | 9.45 in x 6.30 in (240 x 160 mm) |
| Weight | 0.91 lbs (0.4122KG) |
