Overview
The Inventory Master Rfid Card Reader with Display 2D Barcode Scanner is a new portable product, in response to the needs of the Internet of Things. It is a smart highly integrated functionally RFID reader with high processing speed, good portability, and adaptability to various application places. The reader has functions such as UHF-RFID, 4G full Netcom network (data), Wi-Fi, and GPS. At the same time, it can be equipped optionally with barcode scanner modules and camera modules.
Features
- Super Speed Reading
- Powerful multi-tag reading function
- Super Configuration
- Netcom network, Wi-Fi, GPS
- Compact Design
- Using latest environmentally friendly materials injection
- Light Weight
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | GEN2, ISO or IEC 18000-6C |
| Reading Distance | 0 ft to 19.6 ft (0 m to 6 m) |
| RF Output | 0 dBm to 30 dBm, step 3 dB 1 W E IRP |
| WLAN | IEEE 802.11 a/b/g/n 2. 4 GHz and 5 GHz dual band |
| Type External Port | Mini USB Support OTG function |
| Processor | Dual-core 1.0 GHz |
| Operating System | Android 4.2 (Jelly Bean) or Android 4.4 (Kitkat) |
| Display | 4 in (10.1 cm) WVGA TFT BlanView LCD |
| Memory | 1 GB RAM or 8 GB ROM |
| Anti-fall | 4.9 ft (1.5 m) high drop to the concrete floor |
| Audio | Handset, Speaker, Headphone Jack, Microphone I or O |
| Port | USB 2.0 client, OTG |
| Camera | CMOS, 5 megapixels, auto focus and flash function |
| Barcode | 1D laser or 2D barcode scanning |
| Expansion Slot | 1 Micro SD slot (SDHC), 1 SIM slot |
| Notification | Vibrator and LED display, speaker |
| Main Battery | Polymer lithium ion 3.7 V 2260 mAh (rechargeable) |
| Backup Battery | No |
| Power Adaptor | Input AC 110 V to 240V or output DC 5 V 2 A |
| GPS | Built-in antenna |
| Write Distance | 0 ft to 9.8 ft (0 m to 3 m) |
| Anti-Collision | Support |
| RF Output | 1 W EIRP |
| Handle | UHF or HF |
| Handle Battery | Lithium-ion battery 3.7 V 4400 mAh (rechargeable) |
| Communication Standard | MODEM 3G |
| Barcode | 1D laser or 2D barcode scanning |
| HF RFID | Support standards: NFC, ISO15693, MIFARE, ISO14443A / B* Reading distance: 0 in to 3.9 in (0 cm to 10 cm) (internal), depending on the label |
| Humidity | 95 %, non-condensing |
| Safety Drop Height | (2 m) 6.56 ft |
| Operating Temperature | -4 °F to 140 °F (-20 °C to + 60°C) |
| Storage Temperature | -22 °F to 158 °F (-30 °C to + 70 °C) |
| Size | 5.7 in X 2.9 in X 5.0 in (145 mm x 75 mm X 129 mm) |
| Weight | 9.1 oz (259.5 g) |
