Features
- Supports 125 KHz & 13.56 MHz
- EM 4100 or EM 4102
- ISO 14443A + ISO 15693
- S 50 or Desfire or Ultralight
- CSN card read-only
- Wiegand 26, TTL, USB, RS 232, RS 485 for option
Technical Specifications
| Frequency | 125 KHz |
| Protocol | ISO 14443-A |
| Support Cards | EM 4100 EM 4102 and S 50 Ultralight Card |
| Power Voltage | 5 V or 12 V |
| Reading Distance | 0.098 ft to 0.262 ft (3 cm to 8 cm) |
| Interface | Wiegand 26 TTL USB RS 232 RS 485 |
| Application | Access control Resource management Railway inspection |
| Antenna | External. Variety of optional specifications |
| Storage Temperature | -4 °F to 167 °F (-20 °C to + 75 °C) |
| Size | 1.85 in X 1.02 in X 0.20 in (47 mm X 26 mm X 5 mm) |
