Overview
The Inventory Master two-in-one desktop reader is a member of our company’s low frequency 134.2 kHz or FID. The reader circuit and read-write algorithm have been carefully optimized. It has the characteristics of low power consumption, sensitive induction, stable card reading and fast card reading. With this reader software program. With the API interface program provided by this reader, the reader can be quickly integrated into various card issuing, checking in and charging systems.
Technical specifications
| Frequency | 134.2 KHz |
| Support Cards | EM 4305 |
| Size | 4.33 in x 3.15 in x 1.02 in (110 mm x 80 mm x 26 mm) |
| Color | Black |
| Interface | USB |
| Power Supply | DC 5 V |
| Operating Distance | 0 in to 1.97 in (0 mm to 50 mm) (related to the card or the environment) |
| Service Temperature | 14 °F to 158 °F (-10 °C to +70 °C) |
| Store Temperature | −4 °F to 176 °F (-20 °C to +80 °C) |
| Working Humidity | <90 % |
| Read Time | <200 ms |
| Read Interval | <0.5 S |
| Weight | About 4.94 oz (140 g) |
| Cable Length | 55.12 in (1400 mm) |
| Material Of Reader | ABS |
| Operating System | Win XP or Win CE or Win 7 or Win 10 or LIUNX or Vista or Android |
| Indicators | Double Color LED (Red & Green) and Buzzer |
