Features
- Vertical polarization
- N Female connector
- DC ground lightning protection
- Aluminium reflector material
- ABS radome material
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO 18000 6C |
| Polarization | Vertical |
| Connector | N Female |
| Gain | 13 dBi |
| Horizontal Beam Width | Horizontal 120 ° Vertical 15 ° |
| F or B Ratio | ≥ 22 |
| VSWR | ≤ 1.3 |
| Impedance | 50 Ω |
| Maximum Power | 500 W |
| Lightning Protection | DC ground |
| Rated Wind Velocity | 196.85 ft per s (60 m per s) |
| Reflector Material | Aluminium |
| Radome Material | ABS |
| Mounting Hardware | 1.18 in to 2.36 in (30 mm to 60 mm) |
| Size | 47.24 in x 3.94 in x 1.57 in (1200 mm x 100 mm x 40 mm) |
| Antenna Weight | 5.51 lb (2.5 kg) |
