Overview
The Inventory Master Bus Validator is an EMV L1 complied bus validator, which enables rapid fare collection through smart card, NFC processing and QR code ticketing. Its system integration capabilities allow connection to devices such as GPS tracker and Mobile DVR, to obtain the vehicle location and route data for fare collection.
Technical Specifications
| Working Frequency | 13.56MHz |
| Transaction Speed | <0.3S |
| Reading Distance | ≤ 3.93 in (10cm) |
| GPS | Embedded with GPS module for distance-based fare |
| CPU Processor | Quadcore ARM Cortex A7 CPU, 1.1GHz |
| Operation System | Linux |
| Screen Size | 4 inches |
| Resolution | 800 x 480 |
| LCD | TFT Color LCD, with backlight |
| Card Reader | ISO/IEC 14443 Type A&B, Mifare Classic, Mifare DesFire and CPU card based on Mifare PRO |
| SAM Slot | 4 PSAM slots |
| SAM Card Standard | ISO7816 card, 1.8V, 3V or 5V |
| Power Input | DC 8V to 40V |
| Working Temperature | -4°F to 122°F (-20°C to 50°C) |
| Storage Temperature | -40°F to 176°F (-40°C to 80°C) |
| Humidity | 95% RH |
| Dimension | 9.84 in × 6.10 in × 1.96 in (250mm x 155mm x 50mm) |
| Net Weight | 3.30 lbs. (1.50 kg) |
