Technical Specifications
| Relative Humidity | 0 % to 95 % (no condensation) |
| Power Consumption | < 4 VA |
| Frequency Measurement Accuracy | ≤ 0.01 Hz |
| Screen Resolution | 1280 x 800 |
| Screen Type | Color Wide Temperature LCD Screen |
| Measuring Voltage Range | 0 V to 900 V |
| Measuring Current Range | Small Clamp: 0 A to 5 A, 25 A (standard) |
| Middle Clamp: 5 A to 100 A, 500 A (optional) | |
| Large Clamp: 20 A to 400 A, 2000 A (optional) | |
| Charger | AC 220V ±15% |
| Frequency | 45 Hz to 65 Hz |
| Battery Working Time | ≥ 10 hours |
| Harmonic Measurement Times | 2 to 64 times |
| Physical Dimensions | 11.02 in × 8.27 in × 2.28 in (28 cm × 21 cm × 5.8 cm) |
| Max. Torque | Weight |
| Ambient Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Weight | 4.41 lb. (2 kg) |
| Size | 11.02 in × 8.27 in × 2.28 in (28 cm × 21 cm × 5.8 cm) |
