Features
- It has large and medium-sized enterprises.
- The product is equipped with 6 X 2.5Gbps network port.
- Support functions such as intelligent flow control.
- Allow up to 1024 end users to access.
- It serves as the main router in the network.
- Widely used products in small and medium-sized enterprises.
Technical Specifications
| Processor | J6413 4 core, 10nm, 1.8GHz, 1.5M Cache |
| Chipset | SOC |
| BIOS | UEFI BIOS |
| Type | 3200MHz DDR4 SO-DIMM |
| Capacity | 8GB |
| Interface | 1 x 6Gb per s SATA |
| CF | 1 x CF TypeII slot, default 1G SLC CF card |
| HDD | Support 1 x (6.35 cm) 2.5-inch Hard drive bracket with hard drive shockproof function |
| mSATA | 1 x mSATA SSD slot (or CF alternative) |
| Interface | 6 x GbE RJ45 |
| Ethernet Chip | 225V |
| LED | RJ-45 LED Link or Act LED: Green light on when connecting, flashing green light during network communication Speed LED: Orange light at 2.5G, green light at 1000M, and no light at 100M |
| SFP | 2 x 1G SFP ports |
| SFP Chip | Marvell 88E1512 |
| SFP LED | LED: Green light on when connecting, flashing green light during network communication |
| USB | 2 x USB3.0 |
| Console | 1 x Console port, RJ45 |
| Power Switch | ATX switch |
| LED | Layer 1: Hard disk indicator light: Yellow light, flashing when data is read or written Layer 2: Power indicator light: green, power on LED is on Layer 3: green, SFP1 first optical port indicator light Layer 4: green, SFP2 second optical port indicator light |
| Display | 1 x DB-15 VGA, support hot plug |
| USB | 2 x USB2.0 Pin interface |
| Console | 1 x RS-232 Pin, support LCM display module expansion |
| Watchdog | Supports 1-255 second programmable software watchdog and system reset |
| Digital Input and Output | 8-way digital input or output (4-way input or 4-way output) |
| Color | Black, sanded baking paint |
| Front Panel | Silver PVC, frosted |
