Features
- Support full-duplex 10/100/1000 Mbps Ethernet data stream
- Support RFC2544 (Includes: Throughput, Frame loss, Back-to-back and Latency)
- Support Y.1564 (Optional)
- Support RFC3393
- Support L1/L2/L3/L4 BERT test
- Support to generate 8 data streams in maximum (MAC address, VLAN label, MPLS, IPV4/IPV6 address, Payload and Bandwidth)
- Support to set flow priority according to CoS and ToS/DSCP
- Support filter and package capture online
- Support to verify SLA automatically by RFC2544 and Y.1564
- Support dual-port through function
- Support SDT (Service disruption test)
- Support 3 layer COS configuration to verify Metro Ethernet service
- Support to display test result graphically, easier to view.
- Specialized for one gigabit ethernet installation, operation, maintenance and troubleshooting or IP service.
Technical Specifications
| Battery | Rechargeable Li-Lon battery Working time: 8 hour Charging time: <3 hours (typical: 77° F (25°C)) |
| Power Supply | Input: 100V to 240V AC, 50 Hz to 60 Hz, 2A Output: 15V DC, 2A |
| Port | Electrical interface: 2 ports, 10/100/1000M Base-T Optical interface: 2 ports, 100/1000M Base-X User select-able optical module: 850nm, 1310nm, 1550nm |
| Configuration | Monitor/generate, pass-through |
| Encapsulation | Ethernet type II, IEEE802.3 with 802.2, IEEE802.3 with SNAP |
| Traffic Generation | Variable line rate traffic generation, up to full line rate Traffic generate mode: continuous, burst, ramp, n-frame, n-burst, n-ramp Adjustable frame size: 38 bytes to 16000 bytes Frame size: constant, iMAX, random User-defined traffic mix of unicast and broadcast frames Fixed or increment MAC/IP identifier User programmable DSCP/TOS byte Configurable IP and Ethernet source and destination addresses (support IPv4 and IPv6 addressing) User programmable TCP/UDP address Generate pause frames, respond to pause frames Answer incoming ARP, Ping requests (ON/OFF) |
| Stacked VLAN | Up to 3 user-settable VLAN tags Parameters per VLAN tag Ethernet type II 0x8100 (802.1Q), 0x88a8 (802.1ad), 0x9100, 0x9200 or 0x9300 User-defined VLAN ID, CFI, VLAN priority |
| Multi stream | Number of streams: up to 8 streams per port can be activated |
| Error Injection | FCS, IP check sum error, CRC4 error, bit error |
| Alarm Generation | No link |
| Status | Link status, interface type, jabber detected, frames present, MPLS/VLAN, speed, full or half duplex, signal present, bit rate of incoming Ethernet signal, auto negotiation complete Link partner abilities: speed/duplex Indicators of utilization, throughput, error-ed frames Signal level indication for optical Ethernet interfaces |
| Performance Statistics | Utilization, throughput, frame rate |
| Frame Statistics | Total frames, total testing frames, total not testing frames, uni-cast/multicast/broadcast frames, number of pause frames Total VLAN frames Total MPLS frames Total error-ed framed, number of oversized, normal, and runt frame, number of FCS error-ed |
| Frame Distribution Statistics | Total valid/frames, <64, 64 to 127, 128 to 511, 512 to 1023, 1024 to 1518, >1518 |
| Multi stream | Display information per steam Frame loss count/rate, throughput, latency, packet jitter, frames and bytes received and transmitted |
| BER Test | Generation and detection of test pattern, count of errors in received test pattern Pattern generation: layer 1 to layer 4 Frame loss count and frame loss seconds BER measurement results Test pattern: PRBS9, PRBS11, PRBS15, PRBS20, PRBS23, PRBS31, CRPRJ, JTPAT, SPAT, 32bits user defined |
| RFC2544 Test | Switch/router test and single ended network test mode Throughput, frame loss, latency, back-to-back End-to-end network test mode (2 units in local-remote setup) Throughput, frame loss, back-to-back |
| Temperature | Operating: 14 °F to 122 °F (-10 °C to 50 °C) Storage: -40 °F to 158 °F (-40 °C to 70 °C) |
| Size | 3.14 in x 5.31 in x 9.84 in (8 cm x 13.5 cm x 25 cm) |
| Weight | 2.42 lb (1.1 kg) |
