Features
- Full touch screen
- One button testing
- Intelligent link analysis
- Large trace storage
Technical Specifications
| Standard Interface | FC/SC/ST/LC optional |
| LCD Size | 5 inch HD Color touch screen |
| Length Testing | Support |
| Network Cable Testing Function | Can realize network cable open circuit, short circuit, out of order test. Roughly detect the fault locator of the network cable |
| Working Duration | ≥ 10 hours (recording to bellcore TR-NWT-001138) |
| Pulse Width | 5ns, 10ns, 20ns, 50ns, 100ns, 300ns, 1us, 2.5us,10us, 20us |
| Event Dead Zone (m) | 6.56 ft (2 m) |
| Attenuation Dead Zone(m) | 32.80 ft (10 m) |
| Distance Range (Km) | 0.31 mi to 99 mi (0.5 km to 160 km) |
| Distance Uncertainly | ± (1 + 0.005% x Distance + sampling resolution) |
| Loss Measurement Accuracy | ±0.05 dB/dB |
| Data Sampling Point | 12800 |
| Memory Capacity | 1000 Curves |
| Fiber Type | SM |
| Capacity of Screen Touches | > 10 million times |
| Wavelength | 650 nm ± 20 |
| Output Power | ≤ 2 mW Standard |
| Standard Connector | SC/UPC |
| Batteries | 4000 mAh Li-Batteries |
| Size | 10.25 in x 8.07 in x 2.79 in (16.5 cm x 13 cm x 4.5 cm) (L x W x H) |
| Weight | 2.20 lb (1 kg) |
