Technical Specifications
| Color | Metal gray (color can be customized freely) |
| Material | High-quality all aluminum, surface hard anodized |
| Processor | Intel Core Ultra 5 125U (12 core 14 threads, Max Turbo 4.3 GHz, 15W ) Intel Core Ultra 7 155U (12 core 14 threads, Max Turbo 4.8 GHz , 15W) |
| Memory | 2*DDR5 5600 SODIMM memory slot, Max 64 GB |
| NPU | Intel AI Boost (Max Frequency 1.4GHz) |
| Display Chip | Intel Graphics |
| I/O | 1 Power Button, 1 Reset, 1 Type-C (support DP/USB 3.2/PD 5V1A), 1 HD-M-I, 1 DP, 4 USB 3.2, 1 RJ45 COM (suppor Console), 1 SIM Card Slot, 1 DC, 8 Intel 2.5G Lan (1 Intel i226-LM support vPro, 7 Intel i226-V) |
| Expansion Slot | 1M.2 2280 M-Key slot (NVME protocol, PCIE4.0 x4)<br>1M.2 2230 E-key slot (PCIe&USB /CNVio2 ) 1M.2 3052 (2242) B-key slot (USB 3.0 signal, supports 4G/5G), external SIM card slot<br>Expandable interface (not included in standard shipment)：2 USB 2.0, 4Pin GPIO |
| Storage | 1M.2 2280 slot, 12.5-inch HDD/SSD |
| Network | 7Intel i226-V 100/1000/2500M Ethernet<br>1Intel i226-LM 100/1000/2500M Ethernet, support Intel vPro (LAN1) |
| Power Supply | DC 12V |
| Other Function | Power-on, Timed power-on, network wake-up, PXE boot, watchdog (level 0-255), TPM2.0 security encryption |
| Work Temp | 32°F – 104°F (Commercial HDD), -4°F to -58°F (Industrial SSD), Surface air flow (0℃ – +40℃ (Commercial HDD), -20℃ to -50℃ (Industrial SSD), Surface air flow) |
| Work Humidity | 5% ～ 95% non-condensing |
| Dimension | 6.69 × 5.51 × 2.28 in (170 x 140 x 58 mm) |
| Weight | 2.99 lb (1.36 kg) |
| Application | Firewall, VPN, network server, network security, router and other fields. |
