Features
- 10-in-1 Functionality
- Wide Wavelength Support
- 80Km Testing Range
- Accurate Dynamic Range
- Interchangeable FC/UPC Adapters
- Internal Memory Storage
- Visual Fault Locator
- Optical Power Meter
- Pulse Width Adjustment
- Compact, User-Friendly Design
Technical Specifications
| Use | FTTx |
| Warranty Time | 1 Year |
| Network | None |
| Wavelength | 1310nm/1550nm |
| Dynamic Range | 22/20dB |
| Attenuation Dead Zone | 22.97 ft (7.0 m) |
| Event Dead Zone | 3.28 ft (1.0 m) |
| Distance Setting | Max. 49.71 mi (80 Km) |
| Connector | FC/UPC Interchangeable Adapter or Customize |
| Pulse Width | 5ns to 20μs |
| OPM Function | +26 dBm to -50dBm, 850/1300/1310/1490/1550/1625nm, 0.0984 in (0.25 cm)UPP |
| VFL Function | 10mW, 2.5mm Universal Connector |
| OLS Function | Same Wavelength and Connector as OTDR |
| Storage | Internal Memory or TF Card (Optional) |
| Power & Data Port | TYPE-C |
| Power Bank | Type-A 3.7V, 5000mAh |
| Size (HWD) | 63,368.6 in (160,853.8 cm) |
| Weight | About 15.2 oz (430 g) |
