Features
- Integrated OTDR functionality
- Accurate power measurements
- Wide measuring range
- Handheld, portable design
- MPO interface support
- High power stability
- Reliable fiber testing
- Optional 1550nm wavelength
- User-friendly interface
- Durable, compact build
Technical Specifications
| Wavelength | 1550 nm (optional) |
| Output Power | ≥ -5 dBm |
| Spectral Width (FWHM) | ≤ 5 nm |
| Frequency | CW, 270, 1K, 2KHz |
| Power Stability | ≤ ±0.1 |
| Detector Type | Ingas |
| Port | MPO Male connector |
| Measuring Range | +3 dBm to -50 dBm |
| Power Measurement Linearity | ±0.1 dB |
| Power Measurement Uncertainty | ±0.25 dB |
| OLS Wavelength | 1550 nm (optional) |
| OLS Output Power | ≥ -5 dBm |
| OLS Spectral Width (FWHM) | ≤ 5 nm |
| OLS Frequency | CW, 270, 1K, 2KHz |
| OLS Power Stability | ≤ ±0.1 |
| OPM Detector Type | Ingas |
| OPM Wavelength | 850 nm, 1300 nm, 1310 nm, 1550 nm |
| OPM Measuring Range | +3 dBm to -50 dBm |
| OPM Power Measurement Linearity | ±0.1 dB |
| OPM Power Measurement Uncertainty | ±0.25 dB |
| OPM Port | MPO Male connector |
| OPM Resolution Ratio | 0.01 dB |
| OPM Polarity Detection | A, B, C & user-defined |
| OPM Record Storage | Applied |
| Wavelength Test Range | 800 nm to 1700 nm |
| Wavelength (Other) | 850/1300/1310/1490/1550/1625 nm |
| Measuring Range (Other) | +26 dBm to -50 dBm |
| Uncertainty (Other) | ≤ 0.25 dB |
| VFL Wavelength | 650 nm |
| VFL Output Power | 10 mW |
| Display Size | 5.6 in (14.22 cm) TFT color screen |
| Power Supply | 7.4V 4000mAh Lithium battery/Micro USB |
| Automatic Shutdown Time | User-defined optional |
| Low Battery Warning | Icon flashing |
| Communication Interface | Micro USB |
| Standard Configuration | 1. Main device (1) |
| Operating Temperature | 14 °F to 140 °F (-10 °C to +60 °C) |
| Storage Temperature | -13 °F to 158°F (-25 °C to +70 °C) |
| Dimensions | 10.24 in x 6.1 in x 2.87 in (26 cm x 15.5 cm x 7.3 cm) |
| Weight | 44.68 oz (1250 g) |
