Technical Specifications
| Network | Wireless LAN, Wi-Fi, 4G, 3G |
| Connector Type | SC, FC, ST connector |
| Fiber Type | SM (Single Mode), MM (Multi Mode) |
| Display | 5.8 in color LCD with touch screen |
| Wavelength | 1310 nm/1550 nm |
| Measuring Range | 0.31 mi (0.50 km), 0.62 mi (1 km), 1.24 mi (2 km), 3.11 mi (5 km), 6.21 mi (10 km), 12.43 mi (20 km), 24.85 mi (40 km), 49.71 mi (80 km), 74.56 mi (120 km) |
| Optical Power Meter Module | -50 dBm to +26 dBm |
| Optical Light Source Module | 1310 nm/1550 nm/1625 nm |
| Measuring Pulse Width | 5 ns, 10 ns, 50 ns, 160 ns, 320 ns, 500 ns, 1000 ns, 5000 ns, 1000 |
| Ranging Accuracy | ± 2.5 ft (0.75m + Sampling interval + 0.005% x Test distance) |
| Use Type | SM (Single Mode) |
| Place of Origin | China |
| Brand Name | APT |
| Use | FTTX (Fiber to the X: FTTH, FTTB, FTTC) |
| Application | FTTH, FTTB, FTTC |
| Function | Test |
| Size | 8.94 in × 6.3 in × 2.76 in (22.7 cm × 16 cm × 7 cm) |
