Features
- 7 Inch multi touch display
- 40/38 DB dynamic range
- Dual wavelengths testing support
- Macro-bending test capability
Technical Specifications
| IOLA | Multipulse test using a mix of short, medium, and long pulses |
| Display | 7-inch color LCD, Multi-touch screen |
| Connector | FC/PC (1310/1550 nm) interchangeable adapter or customize |
| Measurement Mode | Real time, Average, Automatic |
| Test Range | 0.06 mi to 49.71 mi (0.1 km to 80 km) |
| Wavelength | 1550 (± 20 nm) x ZS1000-A/B both support 1310 (± 20 nm) x Support ZS1000-A only |
| Measurement Time | 5 s to180 s |
| Pulse Width | 5 ns to 20 μs |
| Attenuation Dead Zone | 39.37 ft (12 m) |
| Event Dead Zone | 3.28 ft (1 m) |
| Min. Distance Resolution | 0.32 ft (0.1 m) |
| Loss Resolution (dB) | 0.001 dB |
| Distance Uncertainty (m) | ± (0.8 + 0.005% x Testing Distance + Resolution) |
| OPM Function | +26 to -50 dBm, 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm, FC or SC adapter |
| VFL Function | 10 mW |
| Storage | >10,000 results (SOR or PDF) |
| Battery | 7.4 V/4.6 AH Rechargeable lithium-ion batteries |
| Storage Temperature | -4 ℉ to 140 ℉ (-20 °C to + 60 °C), < 90%RH |
| Operating Temperature | 14 ℉ to 122 ℉ (-10 °C to +50 °C), < 90%RH |
| Size (HWD) | 9.70 in x 6.830 in x 2.75 in (24.65 cm x 17.35 cm x 7 cm) |
| Weight | About 3.41 lb (1.55 kg) |
