Technical Specifications
| Performance | Switching Capacity: 240 Gbps Throughput: 178.56 Mpps MAC Capacity: 32 K |
| Hardware | Flash Memory: 128 MB DRAM: 4 GB |
| Interface | 24-Port 10/100/1000/2500Base-T 6-Port 10G Base-R (SFP/SFP+) 1-Port Console (With RJ-45) |
| Power | Input: AC 100 to 240VAC, 50/60Hz Power Consumption: 75 W |
| PoE | Max PoE Power Budget: 370W Support 24-Ports 10/100/1000 802.3af/at/bt Base-T 15.4 W simultaneously on 24 ports 30 W simultaneously on 12 ports 60 W Individual port |
| System | Management: Device view, Services DNS, SNMP, LLDP, ISDP, Timer Schedule, PoE |
| Switching | Ports Mgmt, LAG, VLANs, Address Tables, STP, Multicast MVR, Auto-VoIP, UDLD, Loop Protect |
| VLAN | 4K VLAN ID, Port VLAN, GARP Switch, 802.1q Port-based VLAN Protocol VLANs, 802.1Q TUNNELING, Voice VLAN |
| Link Aggregation | IEEE 802.3ad with LACP – 12 aggregation groups 1 aggregation group can include up to 8 physical ports |
| QoS | 8 queues per port, Rate Limit (Ingress/Egress), Diffuser Auto QoS, Cos |
| Monitoring | Ports, Mirroring, sFlow, Log |
| Maintenance | Save Config, Reset, File Export, Upgrade, File Management, Troubleshooting |
| Device Type | 2.5G POE++ Network Switch |
| Keywords | 24-Port 2.5Gb Multi-Gigabit POE Network Switch |
| Switch Capacity | 240 Gbps |
| Max PoE Power Budget | 370 W |
| Max PoE Power Budget for Single Port | 60W |
| Uplink Ports | 6 x 10 G SFP+ Port |
| Power Supply | Input: AC 100 to 240VAC, 50/60Hz |
| PoE Standard | 24-Ports 10/100/1000 802.3af/at/bt Base-T |
| DRAM | 4GB |
| Flash Memory | 128 MB |
| Environmental | Operating Temperature: 32°F to 104°F (0℃ to 40℃) Operating Humidity: 20% to 85%RH (Non-Condensing) Storage Temperature: -4°F to 158°F (-20℃ to 70℃) Storage Humidity: 5% to 95%RH (Non-Condensing) |
| Mechanical | Dimension: 17.32 in x 1.73 in x 12.99 in (44 cm x 4.4 cm x 33 cm) |
| Weight | 11.02 lbs. (5 kg) |
