Features
- Touchscreen TFT Display
- Gigabit Ethernet Support
- Advanced Error Injection
- Multi-Stream Activation Capability
- Auto-Negotiation Ethernet Feature
- Comprehensive Performance Statistics
- Compact and Portable Design
- Full and Half Duplex
- Flow Control Enabled
- Monitor and Generate Modes
Technical Specifications
| Use | FTTH |
| Warranty Time | 5 Years |
| Network | TCP, GPRS, WiFi |
| Screen | 3.5-inch TFT touch screen (320×240) |
| Ethernet | 10/100M Base-T, RJ45 |
| Ethernet Features | Auto negotiation, full/half duplex, flow control |
| Configuration | Monitor/Generate, Pass-through |
| Multi Stream | Up to 8 streams per port |
| Error Injection | FCS, IP checksum error, CRC4 error, bit error |
| Performance Stats | Utilization, throughput, frame rate |
| Transmit Stats | Total frames, unicast/multicast/broadcast |
| USB Ports | USB 2.0, Type A (1), Type B (1) |
| Storage | 128 MB |
| EMC Compliance | EN55022/CIPSR22, EN61000-3-2, EN55024 |
| Battery | Rechargeable Li-Ion, 8-hour working time, 3-hour charging time |
| Power Supply | Input: 100 V to 240 V AC, 50 Hz to 60Hz, 2A Output: 15 V DC, 2A |
| Ports | 2 electrical (10/100/1000M Base-T), 2 optical (100/1000M Base-X) with selectable modules (850nm, 1310nm, 1550nm) |
| Encapsulation | Ethernet type II, IEEE802.3 with 802.2/SNAP |
| Traffic Generation | Variable line rate, modes: continuous, burst, ramp, n-frame; Frame size: 38 bytes to 16000 bytes |
| VLAN Support | Up to 3 VLAN tags, configurable Ethernet type, VLAN ID, CFI, priority |
| Alarm Generation | No link |
| Status Indicators | Link status, interface type, utilization, throughput, error frames, signal level |
| Frame Statistics | Total frames, unicast/multicast/broadcast, VLAN/MPLS frames, error-ed frames |
| Frame Distribution | Frame size distribution: <64, 64 to 127, 128 to 511, etc. |
| BER Test | Pattern generation (PRBS9, PRBS11, PRBS15, etc.), frame loss count, BER measurement |
| Service Disruption | Max/Avg disruption, resolution: 0.1 µs |
| Relative Humidity | 0 % to 95 % (non-condensing) |
| Temperature | Operating: 14 °F to 122 °F (-10 °C to 50 °C) Storage: -40 °F to 158 °F (-40 °C to 70 °C) |
| Size | 3.15 in x 5.31 in x 9.84 in (8 cm x 13.5 cm x 25 cm) |
| Weight | 2.43 lb (1.1 kg) |
