Features
- Built in tracking system.
- Supports multiple network system
- Real-time GPS positioning.
- Emergency alert function enabled
- Waterproof and durable design.
Technical Specifications
| Voltage | DC 9-36V, applicable to 12V/24V vehicles |
| Battery | Polymer lithium battery, 3.7V / 5200mAh |
| Working Current | Average current <100 mA@12V |
| Sleep Current | <15mA@12V |
| Recharge | Built-in battery with quick charge support |
| Cellular | – Cat M1: LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26*/B27/B28/B66/B8 – Cat NB2: LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26*/B28/B66/B71/B85 – EGPRS: 850/900/1800/1900MHz |
| Protocol | Embedded TCP/IP stack |
| Sensitivity | -107dBm@850/900MHz -106dBm@1800/1900MHz |
| Output Power | Class 4 (2W)@850/900MHz Class 1 (1W)@1800/1900MHz |
| GPRS Data | GPRS Class 10, Mobile Station Class B |
| GPS | Supports GPS, AGPS, and LBS |
| Antenna Type | Built-in Cellular and GPS antenna |
| I/O Interface | 2 inputs, 1 output |
| AD Interface | 2 ADC inputs, input voltage 0-5V |
| UART | 2 RS232 and 1 RS485 interface |
| LED Indicator | Cellular, GPS, battery |
| Remote Upgrade (FOTA) | Supports remote configuration and firmware upgrade |
| Multiple IP Support | Supports multiple IPs connecting simultaneously |
| Environment | Working Temperature -4 ℉ to 158 ℉ ( -20 ℃ to 70 ℃ ) Storage Temperature –40 ℉ to 185 ℉ ( -40 ℃ to +85 ℃) |
| IP Rating | IP68 |
| Dimension | 4.72 in × 2.76 in × 1.97 in (120 mm × 70 mm × 50 mm) |
