Features
- Advanced Fiber Testing
- Color Display Integration
- Mobile App Control
- Accurate Loss Measurement
Technical Specifications
| RJ45 Test | RJ45 line sequence test according to TIA568-A or TIA568-B standard |
| Optical Interface | OTDR: standard FC/UPC, optional SC/UPC, FC/APC, SC/APC VFL: (0.25 cm) 0.1 in universal port OLS: share the OTDR port OPM: (.25 cm) 0.1 in universal port |
| Electrical Interface | RJ45 ports × 2, RJ45 remote module USB Type-C charging port and data port |
| Wireless | Bluetooth (only for RH0100-D28) |
| Mobilephone APP | Android system (only for RH0100-D28) |
| Data Storage | Pluggable 8 GB micro-SD card |
| Battery | 5000 mAh lithium battery |
| Distance Range | 0.62 mi, 1.24 mi, 3.11 mi, 6.21 mi, 12.42 mi, 24.85 mi, 49.71 mi, 74.56 mi |
| Sampling Points | 64000 |
| Loss Accuracy | 0.1 dB |
| Sampling Resolution | 0.16 ft (0.05 m) |
| Fiber Type | SMF |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Dimension | 7.6 in × 3.69 in × 1.85 in (19.2 cm × 9.38 cm × 4.7 cm) |
| Weight | 1.26 lb. (0.57 kg) |
