HF RFID Reader Module, ISO15693, 13.56MHz, 10-15cm Range – The Inventory Master

Efficient HF RFID reader for inventory management, 13.56MHz, ISO15693, supports RSSI, 10-15cm read range, low power, air-cooled design.

SKU: TIMHMOD-204 Category:

Overview

The Inventory Master HF RFID reader module for Inventory management is a Support Tag RSSI, read or write device and with Inventory management which typical read distance is 3.9 in to 5.9 in. Including Cooling method.



Technical Specifications

Frequency13.56 MHZ
ProtocolISO 15693
Tag RSSISupport
 Power SupplyDC 3.5 V (± 5%)
Current< 80 mA
Cooling MethodAir cooling
Read Distance3.9 in to 5.9 in (10 cm to 15 cm)
Operating Temperature14 oF to 122 oF (-10 oC to 50 oC)
Storage Temperature-4 oF to 140 oF (-20 oC to 60 oC)
