Features
- General antenna for terminal applications with directional feature
- Narrow beam
- High gain
- Circular Polarization
- SMA 50KFD Female connector
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO 18000 6C |
| Gain | 10 dBic |
| VSWR | ≤ 1.3 to 1 |
| Impedance | 50 Ω ± 1 Ω |
| Polarization | Circular Polarization |
| Material | Acrylic Board and Aluminum |
| Color | Milk White |
| Connector Type | SMA 50KFD Female |
| Relative Humidity | 5 % to 95 % |
| Operating Temperature | – 40 °F to 185 °F (- 40 ℃ to + 85 ℃) |
| Storage Temperature | – 40 °F to 185 °F (- 40 ℃ to + 85 ℃) |
| Size | 18.11 in x 8.66 in x 1.38 in (460 mm x 220 mm x 35 mm) |
| Weight | 5.5 lb (2.5 kg) |
