Features
- Aluminum alloy enclosure for excellent heat dissipation, waterproof design for all-weather installation
- High outbound rejection, excellent intermodulation, and spurious emissions
- Modules structure, multi-duplexer, two ports design, and built-in power supply, easy for maintenance and installation
- Adopting cavity filter with high selectivity and low insertion loss eliminates interference between uplink and downlink
- High linearity PA; high system gain
Technical Specification
| Frequency Range | |
| UpLink | 380 to 385/385 MHz to 390MHz |
| DownLink | 390 to 395/395 MHz to 400MHz |
| Max Gain | 90±1dB |
| Downlink to Uplink Separation | 6MHz |
| MGC | ≥ 31dB / 1dB step |
| Gain Control Range | 0 to 31 dB |
| RF Output Power | UpLink: 27dBm, DownLink: 43dBm |
| Noise Figure | ≤5dB |
| Group Delay | 9μs |
| VSWR | ≤1.5 |
| In-band Flatness | ≤3dB |
| Inter-modulation | ≤−45dBC |
| Spurious Emission | ≤−36dBm (9KHz to 1GHz) |
| ≤−30dBm (1GHz to 12.75GHz) | |
| Supply Power | 220VAC, 110VAC, 48VDC, 24VDC |
| Working Environment | Temperature: -13°F to 140°F (-25℃ to +60℃), Humidity: ≤95% |
| Enclosure Protection | IP65 |
| RF Connector | N-F |
| Others | Refer to user manual for more specification |
| Dimension (mm) | 22.83 in × 15.16 in × 9.25 in (58 cm × 38.5 cm × 23.5) cm |
| Weight (Kg) | 57.32 lb (26 kg) |
