High-Performance 13.56 MHz Long Range RFID Reader Module – The Inventory Master

Efficient 13.56 MHz long-range RFID reader supporting ISO 14443 A, Mifare cards, Wiegand 26/34, 0-100 mm read range, operates from 14 °F to 158 °F.

SKU: TIMHMOD-132 Category:

Technical Specifications

Frequency13.56 MHz
ProtocolISO or IEC 14443 A
Support CardsMifare one (S 50, S 70)
Working VoltageDC 12 V
Working Current100 mA
InterfaceWiegand 26 or 34
Distance Of Transmission≥100 M
Read Range0 in to 3.94 in (0 mm to 100 mm)
Lead Length6.89 in ± 1.97 in (180 mm ± 5 mm)
Store Temperature-4 oF to 176 oF (-20 oC to 80 oC)
Working Temperature14 oF to 158 oF (-10 oC to 70 oC)
Size2.56 in x 1.81 in x 0.04 in (65 mm x 46 mm x 1 mm)
Weight0.70 oz (20 g)
