Technical Specifications
| Processor | Up to four 2nd generation intel® xeon® scalable processors, up to 28 cores each |
| Memory | 48 DDR4 DIMM slots, supports RDIMM or LRDIMM, Up To 2933MT/s, 6TB max Up to 12 NVDIMM, 384GB max Up to 24 intel® optane™ DC persistent memory PMem, max 12.28TB, (15.36TB max with PMem and LRDIMM) Supports registered ECC DDR4 DIMMs only |
| Storage Controller | Internal controllers: PERC H330, H730P, H740P, HBA330 External controllers: H840, 12 Gbps SAS HBA Software RAID: S140 |
| Internal Boot | Boot optimized storage subsystem (BOSS): HWRAID 2 x M.2 SSDs 240GB, 480GB Internal dual SD module |
| Drive Bays | Front drive bays: Up to 8x 2.5” SAS SATA (HDD or SSD) max 61.44TB, or up 24 x 2.5” SAS or SATA (HDD or SSD) max 184.32TB, or up To 32 SAS or SATA (HDD or SSD) With up to 4 NVME PCIe SSD max 245.76TB |
| Power Supplies | Gold 1100W -48VDC platinum: 1100W, 1100W 240VDC2 1600W, 2000W, 2400W Hot plug power supplies with full redundancy option 6 Hot plugs fans with N +1 redundancy |
| Embedded Management | iDRAC9 iDRAC direct Quick sync 2 BLE or wireless |
| Bezel | Optional LCD bezel or security bezel |
| OpenManage™ Software | OpenManage enterprise OpenManage mobile OpenManage power center |
| Integrations and Connections | Integrations: microsoft® system center, VMware® vCenter™, BMC true sight , Red hat® ansible® modules Connections: nagios® core & nagios® XI, Microfocus operations manager I, IBM tivoli netcool Or OMNIbus |
| Tools | EMC repository manager EMC update package EMC system update EMC server update utility iDRAC service module iDRAC RESTful API with redfish OpenManage server administrator OpenManage storage services |
| I/O & Ports | Network daughter card options 4 x 1GbE, 4 x 10GbE, 2 x 10GbE+2 x 1GbE, or 2 x 25GbE Front ports: 1 x dedicated iDRAC direct micro-USB, 2 x USB 2, 1 x VGA Optional 1 x USB 3 only offered on the 8 drive Configuration Rear ports: 1 x dedicated iDRAC port, 1 x serial, 2 x USB 3, 1 x VGA Internal port: 1 x USB 3 Video card: 2 x VGA PCIe: up To 12 x gen3 slots, (6×16 slots or 2×16 + 10×8 slots) |
| Dimensions | 6.8 in x 17.37 in x 32.9 in (174.3 mm x 441.16 mm x 835.9 mm) |
| Weight | 123.5lb (56kg) |
