Technical Specifications
| Operating System | Yocto (Linux) |
| CPU | NXP i.MX 8M Plus + Kinara Ara-2, 4 × Cortex-A53 (up to 1.8 GHz) + 1 × Cortex-M7 (up to 800 MHz) |
| GPU | GC7000UL with OpenCL and Vulkan support; OpenGL ES 1.1 / 2.0 / 3.0, OpenCL 1.2, Vulkan |
| NPU & AI Performance | NXP i.MX 8M Plus: 2.3 TOPS Neural Network performanceKinara Ara-2: 40 TOPS (TensorFlow, PyTorch, ONNX AI Model) |
| Memory | NXP i.MX 8M Plus: 4 GB (1 GB – 8 GB optional)Kinara Ara-2: 16 GB |
| Storage | 32 GB eMMC 5.1 (8 – 128 GB optional) |
| Video Interfaces | 1 × HDMI output1 × LVDS screen connector (2×15 P)1 × MIPI DSI connector for panel2 × MIPI CSI connectors (4 lanes) |
| Network Interfaces | 2 × Gigabit EthernetWi-Fi 2.4 G + 5 GBluetooth 5.0 |
| USB Interfaces | 1 × USB 2.0 Type A1 × USB 3.0 Type A1 × USB Type C2 × USB 2.0 4-pin header |
| PCIe Interface | 1 × M.2 Key M for AI module (not usable simultaneously with onboard AI chips) |
| Extended Interface | 1 × Mini PCIe for 4G |
| Communication Interface | 2 × RS232/RS4851 × CAN2 × DI2 × DO |
| Other Interfaces | A53 core debug (UART), I2C touch screen connector, RTC battery, expanded 2×26 P header, 4-pin FAN header with PWM, LCD backlight header, LVDS panel power switch, system boot/upgrade/reset keys, DC jack (12 V / 3 A) |
| Size | 6.77 in × 4.87 in × 1.71 in (172 mm × 123.7 mm × 43.5 mm) |
| Weight | 2.31 lb (1050 g) |
