Overview
High-performance passive RFID tag with ISO15693 & ISO/IEC 18000-6C EPC Class1 Gen2 protocols. PVC materials, up to 32.8 ft (10 m) reading range.
Technical Specifications
Basic Parameters | |
| Types | Passive RFID tag |
| Working Frequency | 13.56 MHz, 860 MHz to 960 MHz |
| Protocol | ISO15693, ISO / IEC 18000-6C EPC Class1 Gen2 |
Performance Parameters | |
| Chip | I CODE SLIX, Alien H3, impinjM4D/M4E/M4QT/M5 |
| Storage | Related to the chip |
| Operating Mode | Read and write |
| Data Retention | > 10 years |
| Writing Endurance | 100000 times |
| Reading Distance | 0 in to 1.97 in (0 mm to 50 mm) 0 ft to 32.8 ft (0 m to 10 m) (the reading range is related to the working condition and reader) |
Physical Parameters | |
| Packaging Materials | PET, PVC, coated paper |
| Antenna | Aluminum etching antenna |
| Craft | 4C Offset printing, Printing ID number |
| Typical Applications | |
| Applications | Library management |
Environment Parameters | |
| Working Temperature | – 13 °F to + 131 °F (-25 ºC to + 55 ºC) |
| Storage Temperature | -31 °F to +167 °F (-35 ºC to + 75 ºC) |
| Size | 1.97 in x 1.97 in (50 mm x 50 mm) can be customized |
