Features
- Non-contract measurement with FMCW working principle
- The beam angle is small, and it is easier for the instrument to avoid inter from a possible obstacle
- Almost unaffected by corrosive vapor and foam
- Be more suitable for used in heavy dusty environments
- The radar’s antenna size is small, and it is easy to be installed
- The upper dead zone is smaller, it is more suitable for the level measurement storage tanks
Technical Specifications
| Measuring Range | 1,000 cm (393.7 in) / 2,000 cm (787.4 in) / 3,500 cm (1,377.95 in) |
| Accuracy | ±0.2 cm (±0.08 in) |
| Power Supply | 24V DC (Two/Four-Wire) or 220V AC (Four-Wire) |
| Single Output | 4mA to 20mA / HART Protocol |
| Process Connection | Thread or Flange |
| Operating Frequency | 80 GHz |
| Enclosure Protection | IP67 (Aluminum Housing) |
| Explosion Proof Grade | Ex ia IIC T6 Ga; Ex d IIC T6 Gb |
| Application | Chemical, metallurgical, food processing, wastewater, and various industrial tanks (e.g., acids, lyes) |
| Features | Anti-corrosion lens antenna, minimal dead zone, high precision, and easy installation |
| Process Temperature Range | -40°F to 302°F (-40°C to +150°C) |
