Features
- High-precision testing
- Universal interface compatibility
- FTTH application support
- Accurate troubleshooting tools
Technical Specifications
| Use | Fiber length measurement, break location detection |
| Fiber Type | Single Mode / Multi Mode |
| Dynamic Range | 43 dB to 45 dB |
| Event Dead Zone | 2.6 ft (0.8 m) |
| Attenuation Dead Zone | 19.7 ft (6 m) |
| Measuring Distance | Up to 111.8 mi (180 km) |
| Reflection Measurement Accuracy | ±3 dB |
| Data Storage | ≥2000 test curves |
| Screen Type | 5.8-inch color touch screen |
| Battery Working Time | ≥10 hours |
| Battery Type | Rechargeable Lithium-ion |
| Optical Connector | Compatible with FC, SC, and ST |
| Wavelength | 1310 nm / 1550 nm |
| Pulse Width | 5 ns to 20 µs |
| Sampling Points | Up to 128,000 |
| Signal Noise Ratio | ≥35 dB |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Dimensions | 16.1 in x 15.4 in x 6.3 in (41 cm x 39 cm x 16 cm) |
| Weight | 4.4 lbs (2 kg) |
