Features
- High-Resolution Touchscreen
- Multiple Test Modes
- Optical Module Self-Test
- Lightweight and Durable Design
Technical Specifications
| Center Wavelength (±20nm) | 850/1300/1310/1550/1625 |
| Dynamic Range (dB) | 22 to 45 |
| Pulse Width | 5 ns to 20 ns |
| Event Dead Zone | 6.56 ft, 4.92 ft, 2.62 ft (2 m, 1.5 m, 0.8 m) |
| Attenuation Dead Zone | 32.8 ft, 18.04 ft, 14.76 ft (10 m, 5.5 m, 4.5 m) |
| Distance Range | 0.31 to 99.4 mi, 0.31 to 149.1 mi (0.5 km to 160 km, 0.5 km to 240 km) |
| Distance Measurement Accuracy (±) | ± (3.28 ft + sample space + measurement distance × 0.005%) |
| Linearity | ±0.05 dB/dB |
| Memory Capacity | 10,000 |
| Fiber Type | SMF |
| Display | 7 in capacitive touchscreen |
| Capacitive Touchscreen | >10 million touches |
| Optical Connector | FC/SC/ST (universal connector) |
| VFL | 650nm±20 |
| Output Power | <1 dBm |
| Interface | FC/UPC |
| Detector Type | InGaAs |
| Wavelength Range (nm) | 800 to 1700 |
| Detection Range (dBm) | -60 to +16 |
| Calibration Wavelength (nm) | 850, 980, 1300, 1310, 1490, 1550, 1625 |
| Linearity | ±5% |
| Battery | Lithium battery |
| Continuous Working Time | >10 hours |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimensions | 8.27 in × 6.30 in × 1.77 in (21 cm × 16 cm × 4.5 cm) |
| Weight | 2.16 lb. (0.98 kg) |
