Technical Specifications
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | EPC global UHF Class 1 Gen 2ISO 18000-6C |
| Materials | Die-cast aluminium + Plastics |
| Input Voltage | DC 12 V to 24 V |
| Standby Current | < 10 mA |
| Work Current | 1000 mA + or – 5% at DC 12 V Input |
| Output Power | 0 dBm to 33 dBm |
| Output Power Decision | ± 1 dB |
| Output Power Flatness | ± 0.2 dB |
| Receive Sensitivity | < -85 dBm |
| Antenna Gain | 4 dBi (Circular) |
| Tag RSSI | Supported |
| Antenna Detector | Supported |
| Ambient Temp Motor | Supported |
| Reading Rate | > 800 tags per sec |
| Host Communication | RS-232, TCP or IP |
| GPIO | 2 input optical coupling2 output coupling |
| IP Class | IP 67 |
| Band Rate | 115200 bps |
| Applications | Vehicle access controlautomatic charging without parkingpersonnel access controllogistics monitoringproduction automation management, etc |
| Humidity | 5 % RH to 95 % RH (no condensation) |
| Operating Temperature | −4 °F to 149 °𝐹 (- 20 °C to + 65 °C) |
| Storage Temperature | −40 °F to 185 °𝐹 (- 40 °C to + 85 °C) |
| Dimension | 5.2 in X 5.2 in X 2.1 in (133 mm X 133 mm X 54 mm) |
| Weight | 26.4 oz (750 g) |
