Technical Specifications
| WiFi | Supports M.2 to connect 5G, Mini PCIe to connect 4G LTE |
| SOC | RockChip RK3568 |
| CPU | Quad-core 64-bit Cortex-A55, 22nm lithography process, frequency up to 2.0GHz ARM G52 2EE OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Embedded high-performance 2D acceleration hardware |
| NPU | D.BTops@INT8, integrated high-performance Al accelerator RKNN NPU Supports one-click switching of Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet |
| RAM | 2GB/4GB/8GB LPDDR4 32Bit, frequency up to 1600MHz, supports all-data-link ECC |
| Storage | 32GB/64GB/128GB EMMC M.2 PCIe 3.0 x 1 (Supports 2242/2280 NVMe SSD) SATA 3.0 x 1 (Supports 2.5″ SSD/HDD) TF-Card Slot x1 (Supports TF card expansion) |
| Ethernet | Supports dual Gigabit Ethernet ports (1000 Mbps) POE+ |
| Display | Supports 4K at 60fps output |
| Serial Port | RS232 x 2, RS485 x 2, Debug serial port x 1, on-board 2-way TTL |
| Operating System | Supports Android 11.0, Ubuntu 18.04 OS |
| Audio | 1 x HDMI audio output, 1 x Earphone output, 1 x Microphone onboard audio output |
| Storage Humidity | 10%RH to 80%RH |
| Operating Temperature | 14°F to 140°F (-10°C to 60°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Size | 7.05 in x 4.14 in x 1.63 in (179 mm x 105.2 mm x 41.5 mm) |
