Technical Specifications
| Chipset | Smart chip |
| Application | Smart factory |
| CPU | Industrial Grade CPU operating at 400MHz |
| Memory | 64M DDR2 RAM, 16M SPI FLASH |
| System | Linux-3.18.27 (32-bit system, 128kB L2 cache) |
| LoRa Data Rate | 292 bps to 5.4 kbps |
| Ethernet Communication Rate | 100 Mbps |
| LTE Communication Rate | 50 Mbps |
| Working Frequency | CN470-510 MHz, EU863-870 MHz, US902-928 MHz, AS920-925 MHz, AU915-928 MHz, KR920-923 MHz, RU864-870 MHz, IN865-867 MHz |
| Max Transmission Power | 26 dBm |
| RX Sensitivity | -142 dBm at SF12 (half-duplex) -138 dBm at SF12 (full-duplex) |
| Channels | 8 Data Channels, 1 Control Channel |
| Communication Interface | 1 LAN, 1 WAN, 1 Wi-Fi, 1 LTE module |
| Input | POE power supply with 48V input (24V to 48V) |
| Power Consumption | 7 W |
| Working Humidity | 5 % to 95 % (no condensing) |
| Ingress Protection | IP67 |
| Installation | Wall-mounted or Pole-mounted |
| Certificate | CE / FCC |
| LoRaWAN Protocol | Supports standard LoRaWAN protocol with global frequency band options |
| Chipset | Utilizes Semtech SX130X chips |
| Data Channels | 8 Data Channels and 1 control channel, with full-duplex/half-duplex options |
| Network Compatibility | Compatible with network servers such as Tencent Cloud, LinkWAN, TTN, Chirpstack, Amazon, etc. |
| Protocol Support | Supports IPv6 and Modbus TCP protocol |
| Transmission Range | Transmission range up to 15 kilometers |
| Protection Rating | IP67 Protection Rating |
| Power Supply | Supports standard PoE (Power over Ethernet) power supply |
| Class Support | Supports Class A / B / C |
| Integrated Antennas | Integrated Wi-Fi / GPS / LTE / LoRa Antenna |
| Working Temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Dimension | 11.34 in x 8.46 in x 2.32 in (28.8 cm x 21.5 cm x 5.9 cm) |
