| Ethernet Port Interface | 1 WAN port and 6 LAN ports |
| Industrial Serial Port | 3 RS485 |
| WIFI | 1 road |
| Optical Fiber | SC port or FC port |
| Function | For smart light pole networking |
| Battery | No battery |
| Input Voltage | DC 24V |
| Wireless Protocol | 4G LTE |
| Optical Fiber Cascade Interface | Gigabit Optical Port, SC port or FC port |
| Optical Fiber Mode | Single-mode single-fiber or single-mode dual-fiber |
| Communication Distance | 20km, optional 100km |
| Connection Mode | Cascade connection, ring connection |
| Industrial Serial Port Form | RJ45T industry terminal |
| Serial Port Type | RS-485 |
| Serial Port Parameters | 1200 to 115200bps, 8 data bits, No parity/odd/even parity |
| Ethernet Port Interface (WAN) | 1 WAN port, 10/100M/1000M adaptive, RJ45 interface |
| Ethernet Port Interface (LAN) | 6 LAN ports, IEEE 802.3, IEEE 802.3u, 10/100M/1000M |
| WIFI Standards | IEEE802.11b/g/n, max bandwidth 54Mbps (b/g), 300Mbps (n) |
| WIFI Security Encryption | WEP, WPA, WPA2 |
| WIFI Modes | STA mode, AP mode, Repeater mode |
| Indicators | 3 (Driver, operating status, network) |
| Antenna Interface | 1 SMA interface, WIFI antenna |
| USB Interface | 1 USB interface |
| Debug Interface | 1 Micro USB interface |
| CPU | NXP LS1012A Cortex-A53, Edge computing, 1G main frequency |
| DDR | 512 MB, expandable to 1 GB |
| FLASH | 8 GB eMMC, expandable to 1 GB |
| Button | 1 Reset button |
| Link Detection | Supports multi-level link detection mechanisms |
| Built-in Watchdog | Equipment self-check technology, automatic self-recovery |
