| Application | INDUSTRIAL |
| Communication Network | Start topology |
| LoRaWAN Protocol | Class A, Class B, Class C |
| Working Frequency | EU433, CN470-510, CN779-787 |
| Communication Distance | 3.728 mi (6 km) |
| Location | GPS, Beidou |
| Wireless Management | WIFI management and upgrade |
| Local Storage | 32G TF card |
| Communication Bandwidth | 125 kHz, 250 kHz, 500 kHz |
| Communication Network | Star topology |
| LoRaWAN Protocol | Class A, Class B, Class C |
| Working Frequency | EU433, CN470-510, CN779-787, EU863-870, US902-928, AU915-928, AS923, KR920-923 |
| Communication Distance (Outdoor) | 6 km |
| Max TX Power | 25 ± 2 dBm |
| RX Sensitivity | Max -140 dBm @ LoRa; -70 dBm @ WiFi |
| Communication Bandwidth | 125 kHz, 250 kHz, 500 kHz |
| Channels | 8 upstream channels, 1 downstream channel |
| Data Loss | No data loss and no relay wireless communication |
| Speed | Link Adaptive Speed |
| Work Mode | Support different frequency and same frequency |
| Location | GPS, Beidou |
| Report To Server | 3G/4G, Wired network |
| Wireless Management | WiFi management and upgrade |
| Local Storage | 32 GB TF card |
| Antenna Interface | I-pex to N type, external |
| LoRa antenna: N-type female, LoRa fiberglass antenna, 2 dBi gain |
| 4G antenna: N-type female, 4G fiberglass antenna, 3 dBi gain |
| WiFi antenna: N-type female, 2.4G fiberglass antenna, 3 dBi gain |
| GPS antenna: N-type female, GPS fiberglass antenna, 4 dBi gain |
| Power | Power options: AC220, POE, Solar power |
| POE port supports auto 10/100 Base-T |
| POE standard: IEEE802.3af/IEEE802.3at |
| Consumption | Standby: Average current 140mA @ 12V |
| Communication: |
| – Transmit current: 550mA @ 12V |
| – Receive current: 420mA @ 12V |
| Working Temperature Range | -40°F to 185°F (-40°C to +85°C) |
| Storing Temperature Range | -40°F to 257°F (-40°C to +125°C) |
