| Operating System | Support Windows 10, Windows 11, Linux |
| CPU | Core i5-8260U (6M Cache, 4 Cores 8 Threads, Base Frequency 1.60 GHz, Turbo Frequency 3.90 GHz) |
| TDP | 15W |
| CPU Lithography | 14 nm |
| Memory | Memory Size: Max 64 GB, Memory Types: 2 x DDR4 SO-DIMM 260 pin, Memory Channels: Dual channels, ECC Memory: Do not support |
| Storage | M.2 SSD: 1 x M.2 2280 M KEY PCIE 3.0, SATA: 1 x SATA 3.0 Slot for (6.35 cm) 2.5-inch HDD or SSD, MSATA: No MSATA slot |
| Graphics | Processor Graphics: UHD Graphics 620, HDMI: 1 x HDMI 4096 x 2160 at 30 Hz (4K) + 1 x HDMI 4096 x 2160 at 60 Hz (4K), VGA: 1 x DP 4096 x 2160 at 60 Hz (4K) |
| Power Specification | Adapter Output: DC 12V or 5A, Adapter Input: AC 110V to 240V, 50 or 60 Hz, Consumption: 50W, Auto Power-On: Support Auto Power-On Function |
| I and O Interfaces | USB Port: 4 x USB 3.0 port, 2 x USB 2.0 port, Audio: 1 x 0.13 in (3.5 mm) MIC in & SPK out, Audio Cards: USB Audio Device, Video: HDMI 4096 x 2160 at 30 Hz + HDMI 4096 x 2160 at 60 Hz + DP 4096 x 2160 at 60 Hz 3 Displays, LAN Port: 2 x RJ45 Lan Gigabit Ethernet Controller, Realtek 8168 or 8111, COM Port: 2 x RS232 COM port, support RS422 or RS485 COM port, GPIO: 1 x 14pin GPIO Phoenix Terminal (5 x Input, 5 x Output GPIO), WIFI: Inside WIFI and Bluetooth Combo |
| BIOS | Support RAID, AUTO POWER-ON, Wake On LAN, Resume by Alarm, PXE |
| SIM | 1 x SIM slot, support Nano-SIM, SIM Size: 0.35 in x 0.47 in (9 mm x 12 mm) |
| Humidity | 30%RH to 90%RH |
| Operating temperature | 14°F to 140°F (-10°C to 60°C) |
| Size | 8.07 in x 4.92 in x 2.09 in (205 mm x 125 mm x 53 mm) |
| Weight | 2.65 lb (1.2 kg) |
