Technical Specifications
| Computing | |
| MT7628, DDR2 RAM | 128 MB |
| Frequency | 2.4 GHz (802.11 b / g / n) |
| MIMO | 2 x 2 |
| Wi-Fi Feature | |
| RX Sensitivity | -95 dBm (Min) |
| TX Power | 20 dBm (Max) |
| Operation Channels | 2.4 GHz: 1-13 |
| SX1303 mPCIe Card (Connects maximum of two) | |
| Channels | 8 Channels (16 Channels optional) |
| LoRa Feature | |
| RX Sensitivity | -139 dBm (Min) |
| TX Power | 17 dBm (Max) |
| Listen Before Talk | Yes |
| Frequency | EU433 / CN470 / EU868 / US915 / AS923 / AS923-1 / AS923-2 / AS923-3 / AS923-4 / AU915 / IN865 / KR920 |
| LTE FDD | B1 / B3 / B7 / B8 / B20 / B28A |
| Cellular Feature | Available with RAK7289C V2 |
| WCDMA | B1 / B8 |
| GSM/EDGE | B3 / B8 |
| LTE FDD | B2 / B4 / B5 / B12 / B13 |
| WCDMA | B2 / B4 / B5 |
| Power Supply | PoE (IEEE 802.3af): 37 – 57 VDC |
| ETH | RJ45 (10 / 100 M) |
| Antenna | |
| LoRa | 1 or 2 N-Type connectors |
| LTE | Internal antenna |
| Wi-Fi | Internal antenna |
| Ingress Protection | IP67 |
| Enclosure Material | Aluminium and plastic |
| Operating Temperature | -22 °F to 131 °F (-30 °C to 55 °C) |
| Installation Method | Pole or wall mounting |
| Built-in Network Server | Full LoRaWAN support V 1.0.3 |
| OpenVPN | Yes |
| Software and UI | Sits on top of OpenWRT |
| LoRaWAN Stack Support | Full support with Semtech SX1303 |
| LoRa Frame Filtering | Node whitelisting |
| MQTT v3.1 Bridging | With TLS encryption |
| Buffering of LoRa Frames | In Packet Forwarder mode (no data loss) |
| Full-duplex | Optional |
| Listen Before Talk | Optional |
| Fine Timestamping | Optional |
| Protocol | Class A, Class B, Class C |
| Communication Distance | 3.73 miles (6 km) |
| Local Storage | 32G TF card |
| Certification | CE FCC |
