Overview
High-performance label printer with multiple print modes, resolutions, and interfaces, ideal for various barcode and label printing applications
Technical Specifications
| Print Mode | Direct Thermal and Thermal Transfer |
| Print Resolution | 203 dpi 300 dpi 600 dpi |
| Max Print Speed | 10 ips 8 ips 5 ips |
| Rfid Encoder | Supports UHF EPC Gen 2, ISO 18000-6C protocols (Only available for RFID models) |
| Max Media Width | 4.41 in (112 mm) |
| Max Print Width | 4.25 in (108 mm) 4.16 in (105.7 mm) 4.16 in (105.6 mm) |
| Max Print Length | 315 in (8000 mm) 157 in (4000 mm) 40 in (1016 mm) |
| Mpu | 64-bit, quad Arm® Cortex®-A53 core, maximum operating frequency 1.8 GHz |
| Gpu | GC Nano Ultra 3D (1 shader) &GC320 2D OpenGL ES 2.0 |
| Memory | 2 GB DDR4 RAM, 8 GB managed NAND flash |
| *Heat™ Level | I |
| Media Roll | Maximum Media Width: 4.33 in (110 mm) Minimum Media Width: 0.98 in (25 mm) Maximum Outer Diameter: 6 in (152 mm) Inner Diameter: 1.5 in (38.1 mm) |
| Minimum Label Length | Tear-off: 0.2 in (5 mm) |
| Peel-off: 0.47 in (12 mm) | |
| Cutter: A150/A400: 0.79 in (20 mm) AG120/AG300: 0.51 in (13 mm) | |
| Media Thickness | 0.003 in to 0.008 in (0.08 mm to 0.2 mm), including liner |
| Interfaces | RS-232 Serial, 10/100/1000Mbps Ethernet, USB DEVICE 2.0, USB HOST |
| Ribbon | Maximum Length: 984.25 ft (300 m) Maximum Outer Diameter: 2.75 in (70 mm) Inner Diameter: 1 in (25.4 mm) Ink side: Out |
| Width: 0.79 in to 4.33 in (20 mm to 110 mm) | |
| Media Sensor | Reflective (Adjustable) and Transmissive (Two positions) |
| Fonts | Five built-in dot matrix fonts, which include Basic Latin and Latin-1 Supplement character sets. Two built-in scalable fonts. One supports Latin, Greek and Cyrillic scripts, and the other is a GB18030 Chinese character set specifically. User downloadable TrueType fonts. |
| Barcode Types | 1D Barcode: Code 39, Code 93, Code 128/subset A, B, C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc. 2D Barcode: MaxiCode, PDF417, Datamatrix, QR Code, CS Code, etc. |
| Lcd Display | 4.5 in LCD Capacitive Touchscreen |
| Power Source | 100 VAC to 240 VAC, 50 Hz to 60 Hz |
| Dimensions | 10.58 in (268.8 mm) x 13.88 in (352.5 mm) x 7.80 in (198.2 mm) |
| Optional Items | External Label Rewinder, External Media Stand, and Cutters |
| Operating Environment | Temperature: 32° F to +104° F (0° C to 40° C) Relative humidity: 5 % to 85 % non-condensing |
| Storage Environment | Temperature: -40° F to +140° F (-40° C to 60° C) Relative humidity: 5 % to 85 % non-condensing |
| Weight | 18 lbs (8.2 kgs) |
