Features
- Adjustable Output Voltage
- Maximum Output Current
- LCD Display
- Lightweight Design
Technical Specifications
| Output Voltage | Adjustable DC voltage, full isolation |
| Maximum Output Current | 0 A to 150 A |
| LCD Display | Digital AC/DC volt-ampere meter, voltage, current, stopwatch |
| Stopwatch | Range: 0.0000 to 999999 s, Accuracy: ±5 ms, Resolution: 0.1 ms |
| Internal Ammeter | 0.000150.0 A (internal), 0.0006.000 A (external) |
| Internal Voltmeter | 0.0 V to 600.0 V (AC/DC), Accuracy: 0.5%, True RMS (AC), Average (DC) |
| Resistance Range | 0.5 Ω to 2.5 kΩ |
| Capacitor Range | 10 μF, Maximum voltage AC 450 V |
| Auxiliary Contacts | Max current: 1 A, Max voltage: AC 250 V or DC 120 V |
| Rated Input Power | AC: 220 V ± 10 %, 1000 VA, 50 Hz |
| AC Output Range | 010 A (90 V to 80 V), 040A (25 V to 22 V), 0100 A (10 V to 8 V), 0250 AC (250 V to 240 V) |
| DC Output Range | 0 V to 300 V DC (320 V to 250 V) |
| DC Auxiliary Output | 0110 V (120 V, 0.5 A), 110220 V (220 V, 0.5 A) |
| Operating Environment | Temperature: 14 ℉ to 104 ℉ (-10 to 40 °C), Humidity: <80% |
| Dimensions | 12.59 in x 10.23 in x 9.05 in (32 cm x 26 cm x 23 cm) |
| Weight | 35.27 lb. (16 kg) |
