Features
- Provides virtualization and saves floor space by running multiple workloads
- Managing the exponential growth of data volumes, including all kinds of data
- Storage centric applications
- Data warehousing/ analytics
- Customer relationship management
Technical Specifications
| Number of CPU Threads | 8, 4 |
| Processor | Supports up to 2 Intel Xeon third-generation scalable family processors or Montage Jinsu @ processor series, each with up to 40 cores and a maximum power of 270W |
| Memory | Supports up to 32 DDR4 memory slots, with a maximum rate of 3200MT/s, RDIMM or LRDIMM, and a single processor with a maximum capacity of 6TB. |
| System Architecture | X86 Server |
| Storage Controller | No onboard array controller. Support SATA RAID 0/1/10/5 Optional HBA card and array card based on standard PCle plug-in |
| Storage | Support up to 41 hard drives (37 2.5-inch hard drives, 4 3.5-inch hard drives) Support up to 20 3.5-inch hard drives (12 front, 4 internal expansions, 4 rear expansion) Support up to 37 2.5-inch hard disks (25 front, 8 internal expansion, 4 rear expansion); support SAS pr SATA HDD or SSD hard disk, support front or built-in NVMe hard disk, support up to 32 NVMe hard disk slots, Support PCle NVMe storage accelerator card; support SATA and PCle M.2 options, support 2 Micro SD card kits |
| Network
| There is one 1Gbps dedicated management network port on board,and up to two OCP 3.0 network cards can be selected, which can be extended with 4x1GE electrical ports or 2x10GE switch/optical ports or 2x25GE optical ports; optional network adapters based on standard PCle slots, supporting 1 /10/25/40/100/200 GE network card, IB card |
| Expansion Slot | Support up to 14 PCIe 4.0 standard slots and 1 0CP 3.0 slot |
| Interface | The home is equipped with 1 front VGA, 1 rear VGA and 1 audit port, 6 USB 3.0 (2 front, 2 rear, 2 built-in), 1 front dedicated management interface |
| GPU Support | Supports up to 4 double-width GPU cards or 14 single-width GPU cards |
| Optical Drive | Support external optical drive |
| Manage | IDM agentless management tool (with independent management port) and H3C FIST or FIST management software, support LCD touchable intelligent management module, support 64M local video memory; optional U-Centre data centre management platform |
| Safety | Support security chassis, TCM/TPM security module, two-factor authentication |
| Power and Cooling | Optional Platinum 550W or 800W or 850W or 1200W or 1300W or 1600W or 2000W 1+1 redundant power supply; support hot-swappable redundant fans |
| Server Type | Rack |
| Supporting Memory Capacity | 6 tb |
| Workstation Type | Desktop Workstation |
| Transport Package | Cartons |
| Platform | PC workstation |
| Production Capacity | 5000 pieces per month |
| Hard Disk Capacity | >= 1 TB |
| Appearance/Chassis Dimensions | 3.44 in x 17.54 in x 29.45 in(87.5mm (height) x 445.4mm (width) x 748mm (depth) (without safety panel)) 3.44 in x 17.54 in x 30.55 in (87.5mm (height) x 445.4mm (width) x 776mm (depth) (including safety panel)) |
