Technical Specifications
| Working Frequency | 433 / 470 / 868 / 915 / 923 MHz |
| Protocol | Standard LoRaWAN Protocol |
| Antenna | LoRa / 4G / Wi-Fi / ZigBee / GPS Antenna |
| Certification | CE, FCC, RoHS |
| Warranty | 3 Years |
| Type | Intelligent Gateway Devices |
| Function | Wireless Data Transmission |
| Network Type | 4G |
| Interface – Antenna | 4G: NJ female connector; Wi-Fi: NJ female connector; LoRa: NJ female connector |
| Reset Button | RESET button (restore to factory settings) |
| Ethernet Interface | 1 x WAN 10 / 100 Mbps adaptive ethernet interface |
| Power Range and Supply | AC 110V to 277V, Support POE (Power over Ethernet) |
| Working Power Consumption | < 52W |
| Relative Humidity | <= 95 % (non-condensing) |
| Standard and Frequency Band | ISM Band: 868MHz, 915MHz |
| Horizontal Bandwidth | Up to 20MHz |
| CPU | Specific CPU model if available |
| Flash | 128 MB |
| Working Frequency | FDD LTE: B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B14 / B17 / B20 / B28 TDD LTE: B38 / B40 / B41 1xRTT CDMA: B1 / B2 / B5 CDMA2000 EVDO: BC0 / BC1 / BC10 GSM: 850 / 900 / 1800 / 1900 MHz |
| Transmission Speed | LTE-FDD: Max 100 Mbps (DL), Max 50 Mbps (UL) LTE-TDD: Max 61 Mbps (DL), Max 18 Mbps (UL) HSPA+: Max 21 Mbps (DL), Max 5.76 Mbps (UL) UMTS: Max 14.4 Mbps (DL), Max 2 Mbps (UL) GPS: Max 66 Mbps (DL), Max 6.0 Mbps (UL) |
| Transmission Power | FDD LTE: Max +23 dBm TDD LTE: Max +23 dBm USDC CDMA: Max +24 dBm GSM: 33 dBm for 850 / 900 MHz, 30 dBm for 1800 / 1900 MHz |
| Receiving Sensitivity | FDD LTE: -98 dBm (20 MHz) TDD LTE: -96 dBm (20 MHz) USDC CDMA: -121 dBm HSPA+: -109 dBm (20 MHz) GSM: -100 dBm (850/900 MHz), -102 dBm (1800/1900 MHz) |
| Working Temperature | -4 °F to 176 °F (-20 °C to 80 °C) |
| Storage Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Dimension | 8.87 in x 8.86 in x 3.11 in (22.53 cm x 22.53 cm x 7.93 cm) |
