Features
- Accurate Vibration Sensing
- Multi-Axis Measurement
- Stainless Steel Build
- Wide Frequency Support
Technical Specifications
| Theory | Temperature and Vibration Sensing |
| Output | RS485/4-20mA/0-5V/0-10V/WIFI/LORA |
| Voltage Supply | DC10-30V or 3.6V Lithium Sub-Battery |
| Mounting Type | Thread, Magnetic, or Adhesive Installation |
| Resolution | 0.1°C Temperature, 0.1 mm/s Vibration Velocity |
| Frequency Range | 10 Hz to 1600 Hz, 10 Hz to 5000 Hz |
| Vibration Speed Range | 0 to 50 mm/s |
| Vibration Speed Accuracy | ±1.5% FS (@1kHz, 10mm/s) |
| Protection Class | IP67 |
| Customized Support | OEM, ODM |
| Measuring Direction | 1-Axis or 3-Axis |
| Surface Temperature Range | -40 °F to 176 °F (-40 °C to 80 °C) |
| Operating Temperature | -40 °F to 176 °F (-40 °C to 80 °C), 0 to 80% RH |
| Features | Stainless Steel Build |
| Size / Dimension | 6.3 in x 6.3 in x 3.1 in (16 cm x 16 cm x 8 cm) |
