Technical Specifications
| Voltage – supply | 10 V to 30 V DC±10% |
| Laser source | Semiconductor laser diode |
| Measuring distance | 2.36 in to 393.70 in (0.06 m to 10 m) |
| Accuracy | 1.57 in (40 mm) |
| Angle resolution | 0.25° |
| Scan time | 25msec/scan |
| Noise | <25 dB |
| Interface | Ethernet 100BASE-TX |
| Synchronous output | NPN open collector |
| Interface | Power and I/O interface: 39.37 in (1m) cableEthernet: 11.81 in (0.3 m) cable |
| Vibration | Double amplitude 10 Hz to 55 Hz, |
| Impact | 196 m/s2, 10 times, X, Y, Z direction |
| Protection level | IP 65 |
| Humidity | < 85%RH |
| Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Weight | 0.28 lb (130 g) |
